DN-10 PEDAL/STEP WELDING MACHINE
Type: DN10
Power Supply Voltage (V/Hz): SIMPLEKS 380V/50Hz
Rated Input Power (KW): 10
Rated Input Current (A): 26.3
No-Load Voltage (V): 1.65-2.4
Rated Load Duration (%): 10
Adjustment Level: 4
Welding Time (S): 0-5.99
Welding Thickness (MM): 260
Cooling Method: COLD
Weight (KG): 70
DESCRIPTION
This product adopts lever pedal type spring pressure structure, which is easy to operate and maintain. It adopts thyristor non-contact switch circuit, which has fast and reliable shutdown time. The welding time is adjustable and the welding repeatability is good. It is widely used in automobiles and aviation. Construction, machinery, metal products, electrical switches and other industries, in the welding of low-carbon steel plates, wires, stainless steel plates and other materials
