G10 PNEUMATIC JACK HAMMER MACHINE
G10 pneumatic pick is mainly used to break reinforced concrete, cement, soil,
rock, road surface, construction.
Specifications
Full length of the fuselage, : 570mm
heavy body, : 10.6kg
cylinder diameter, : 38mm
hammer stroke, : 155mm
Hammer weight, : 0.9kg
Working air pressure: 5 BAR
Impact energy: 39.4J
Impact frequency: 18.5Hz
AIR consumption: 19L/s
Inner diameter of trachea: 19mm
PNEUMATIC BOBOK DRILLING MACHINE G16
G16 pneumatic pick is mainly used to break reinforced concrete, cement, rock,
road surface, construction.
Specifications
Full length of the fuselage, : 600 mm
heavy body, : 12.6kg
cylinder diameter, : 38 mm
hammer stroke, : 159 mm
hammer weight, : 9 kg
working air pressure, : 6 BAR
impact energy: 50J
impact frequency, : 15.5Hz
air consumption, : 25L/s
inner diameter of trachea: 16mm
